Big Creek, Shaver Lake Dam

Description: Big Creek, Shaver Lake Dam - Looking northward across Stevenson Creek channel over excavation for Shaver Dam and showing in upper left-hand corner the trestle leading to the crushing plant. The secondary crusher, together with bins over which screens will be installed, is just beginning to show up in this picture. It will be interesting to compare this picture with those which I expect to have taken on September 1st as there will be quite a contrast and a large amount of work will be shown as having taken place during the month of August. .
Type: Visual Materials(Opens in new tab)
Date: 8/2/1926
Call number: photCL SCE 02 - 14047
Find out more: View in the Huntington Digital Library(Opens in new tab); View in the Library catalog(Opens in new tab)
