Big Creek, Florence Lake Dam

Description
Big Creek, Florence Lake Dam - View of downstream side of Arch 53, lake elevation 7261.90. Note slight dampness along 7252 joint 5' left to 20' right of centerline, also trace of asbestile waterproofing applied on upstream face duing spring of 1941 showing through joint at elevation 7260 5' left of centerline.
Type
Visual Materials(Opens in new tab)
Date
6/10/1942
Call number
photCL SCE 02 - 24737
Find out more
View in the Huntington Digital Library(Opens in new tab)
View in the Library catalog(Opens in new tab)
