Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Testing for leaks on Arch 13 with saturated soap solution while steel is subjected to approximately 3/4 lb. air pressure.
photCL SCE 02 - 24877
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Arch #13 Close-up of side seals. The exposed portion of the 24" steel plates imbedded 12" in the groin gunite was bent over the ends of the courses of face steel and welded.
photCL SCE 02 - 24707
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Close-up of groin between Arch 13 & 14, showing 24" sealing plate imbedded in gunite filler.
photCL SCE 02 - 24199
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Close-up of gunite key at base of Arch #13, showing evidence of back leakage. Gunite key was covered with asbestile on November 25, 1942.
photCL SCE 02 - 24825
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Close-up of striations caused by ice on surface of J-M waterproofing on Arch 54 near 54-55 groin. This waterproofing was applied in Dec. 42.
photCL SCE 02 - 24748
Big Creek, Florence Lake Dam
Visual Materials
Big Creek, Florence Lake Dam - Method of waterproofing day's work joints on Arch 52, before guniting. 6" strips of asphalt impregnated felt was tacked to the arch between two applications of asbestile waterproofing.
photCL SCE 02 - 24724
